THE ORIGINAL –
PREMIUM SOLID ACRYLIC LETTERS
TO CREATE THE HIGHEST POSSIBLE ATTENTION!
Our solid acrylic letters of the LPFLEX product family offer
the best possible illumination in even the smallest space
via single LED assignment – LPFLEX is versatile and
offers project-specific solutions.
In addition to LPFLEX, we also offer efficient SMD-stripe
variants in a separate product line.
LPFLEX LETTER PROFILES
LP 1 – Fully side-lit letters
| Faces: | opaque, typically vinyl but metal overlays possible |
| Returns: | fully illuminated |
| Backs: | blockout vinyl |
| Letter thickness: | 15 – 30 mm |
| Example: | Torshov Sport |
LP 1 – Partial side-lit letters
| Faces: | opaque, typically vinyl but metal overlays possible |
| Returns: | upper 1/3 portion illuminated, rest painted opaque |
| Backs: | blockout vinyl |
| Letter thickness: | 20 – 30 mm |
| Example: | HUGO BOSS |
LP 3 – Halo-lit letters
| Faces: | painted opaque |
| Returns: | painted opaque |
| Backs: | illuminated, diffuser vinyl applied |
| Letter thickness: | 15 – 30 mm |
| Example: | Stockholm Gas |
LP 3 – Halo-lit and partial side-lit letters
| Faces: | painted opaque |
| Returns: | lower 1/3 portion illuminated, rest painted opaque |
| Backs: | typically illuminated, diffuser vinyl applied |
| Letter thickness: | 20 – 30 mm |
| Example: | HSBC |
LP 4/6 – Face-lit letters
| Faces: | illuminated |
| Returns: | painted opaque (optionally upper 1/3 portion illuminated) |
| Backs: | painted opaque |
| Letter thickness: | 30 – 33 mm |
| Example: | norli |
| LP 6: | lasercut possible |
LP 5 – Push-through
LED unit for use in blade signs and lightboxes.
| Faces: | illuminated/ opaque vinyl |
| Returns: | illuminated (can be painted on request) |
| Backs: | opaque vinyl |
| Letter thickness: | 3 – 20 mm |
| Example: | KICKS |
LP 7 – Neon-look mini
Exposed outline to imitate double-stroke neon, white lit.
Completely rounded in router finish
| Width of outline: | 4/6/10 mm |
| Faces: | outline illuminated, rest of face recessed with 1mm metal inlay |
| Returns: | opaque portions in opaque vinyl |
| Backs: | blockout vinyl |
| Letter thickness: | 30 – 36 mm depends from finish |
| Example:/strong> | mayday |
LP 9 – Neon-look Standard
White acrylic body with colored acrylic face.
Clear overlay with rounded and polished edges. Continuous stroke of 12mm or 16mm.
| Continuous stroke: | 12mm or 16mm |
| Faces: | lluminated |
| Returns: | opaque vinyl |
| Backs: | blockout vinyl |
| Letter thickness: | 30 mm |
| Example: | KICKS |
LP 9 – Neon-look Premium
White acrylic body with colored acrylic face.
Clear overlay with rounded and polished edges. Continuous stroke of 12mm or 16mm.
| Faces: | illuminated (color determined by acrylic face – middle layer) |
| Returns: | opaque vinyl |
| Backs: | blockout vinyl |
| Letter thickness: | 36 mm |
| Example: | DKNY |
UNLIMITED POSSIBILITIES
Bining
Control
Problem
Replacement letters dont’t fit in existing letterset
Quality Circle Solution
LPFLEX =
specified LED color/replacement letter fit
Color Shift Control
Problem
Fading to blue or yellow (color-shift)
Quality Circle Solution
LPFLEX =
stable white color
Degration
Control
Problem
High light-loss
(degradation)
Quality Circle Solution
LPFLEX =
low light-loss over time
Consistency Control
Problem
Unintentional ”hot spots” due to unsifficant LED population
Quality Circle Solution
LPFLEX =
individually placed LEDs (controlled lighting)
LPFLEX = 100% Qualität
Own binning robot to sort LEDs
Specified LED color to make fitting replacement letters possible*
Mass production
Low degradation means less than 10% light loss*
Single LEDs for homogeneous and consistant look
No color-shift/LEDs are not turning blue or yellow*
The MAAS+ROOS
360° SUSTAINABILITY
APPROACH
Sustainability has always been a high priority at MAAS +ROOS and it is part of our corporate culture. We see it as our entrepreneurial duty to protect our resources and the environment.
We do not primarily focus on the trading of emissions. Instead, we lower our emissions and use of raw materials in production and logistics.
We complete this approach by recycling everything from aluminium and steel to packaging materials like cardboard and plastic wrapping.
Production
State-of-the-art production facilities.
Solvent free powders and waterbased paints.
Certification: ISO 9001 and ISO 14001.
Logistics
Co2 savings through production closer to the customer – in Germany, Dubai and India.
CO2 savings through optimized logistics routes and group transports.
Reduction of packaging materials through delivery to many markets with own means of transport.
Recycling
We separate over 25 materials and return them into the circulation
Fine-particle dust extraction throughout entire production area
ISO 14001 certification underlines a comprehensive environmental policy.
